LiteOn SLW 831SX

Apr 27,2006 0

12. DVD Writing Quality - Page 3



Review Pages

1. Introduction
2. Reading Tests
3. CD Error Correction
4. DVD Error Correction
5. Protected Discs
6. CD Recording Tests
7. CD Writing Quality - Plextools
8. CD Writing Quality - Clover System
9. DVD Writing Tests
10. DVD Writing Quality - Page 1
11. DVD Writing Quality - Page 2
12. DVD Writing Quality - Page 3
13. DVD Writing Quality - Almedio
14. DVDR DL - Page 1
15. DVDR DL - Page 2
16. 831SX vs SA300 - Page 1
17. 831SX vs SA300 - Page 2
18. 831SX vs SA300 - Page 3
19. 831SX vs SA300 - Page 4
20. Advanced Features
21. Conclusion



In order to test the writing quality and readability of the burned media we are used two readers with two software applications:

  • The LiteON SOHD-167T with patched firmware being able to read DVD5 up to 16X CAV and DVD9 up to 10X CAV. For the transfer rate tests we used the latest Nero CDSpeed version.
  • The Plextor PX-716A with the latest available firmware. For scanning the disc, we used the latest PlexTools version at 2X CLV reading speed, BURST mode, with middle accuracy.

In general, a "perfect" disc should have a smooth reading curve, very low PIE/POE and zero (0) POF error rates. Most times however, even though a disc has very low PIE/POE error rates, the reading curve may not be smooth containing speed drops. Due to the fact that we oversped the reading capabilities of the LiteON SOHD-167T, such drops are expected, especially near the outer area of the disc.

The measurements below should be taken not as the absolute criteria of the burning quality, but as an indication level.

4X ±RW Writing Speed

  • MKM DVD+RW 8X @ 4X

  • Ricoh DVD+RW 8X @ 4X

  • Verbatim DVD-RW 6X @ 4X

  • Traxdata DVD-RW 6X @ 4X

- Summary

According to both Plextools and CDSpeed, only -RW media managed to report barely acceptable results. According to CDspeed Q-Check, the transfer rate graphs are shaky and the Plextools scans have among other things, high POE values. Overall, to poor writing quality.
