Optiarc AD 7260S review

Oct 22,2010 0

5. CD/DVD Writing quality tester - IQB Omni CD DVD Analyzer by Quantized



Review Pages

1. Features, specifications
2. CD, DVD reading
3. Reading of defected CDs
4. Reading of defected DVDs
5. CD/DVD Writing quality tester - IQB Omni CD DVD Analyzer by Quantized
6. CD-R writing - Verbatim CD-R 48x
7. CD-R writing - Memorex (Ritek) CD-R 48x
8. CD-RW writing - Verbatim 32x CD-RW
9. DVD-R writing - Philips DVD-R 16x
10. DVD-R writing - Verbatim DVD-R 16x
11. DVD-R writing - Maxell (Ritek) DVD-R 16x
12. DVD-R writing - Ridisc DVD-R (TTH02) 16x
13. DVD-R writing - Taiyo Yuden DVD-R 16x
14. DVD+R writing - Philips DVD+R 16x
15. DVD+R writing - Moser Baer India DVD+R 16x
16. DVD+R writing - Verbatim DVD+R 16x
17. DVD+R writing - Taiyo Yuden DVD+R 16x
18. DVD+R DL writing - Verbatim DVD+R DL 8x
19. DVD-R DL writing - Verbatim DVD-R DL 8x
20. DVD-R DL writing - Verbatim DVD-R DL 12x
21. DVD+RW writing - Verbatim (MKM A03) DVD+RW 8x
22. DVD-RW writing - Verbatim DVD-RW 6x
23. DVD-RAM writing - Maxell DVD-RAM 5x, 12x
24. Summary of CD/DVD writing tests, Booktype
25. Final words



All CD/DVD writing quality tests are done using the IQB Omni CD DVD Analyzer by Quantized. The IQB Omni from Quantized Systems is a physical disc analyzer, covering all CD and DVD formats, designed to meet the Quality Control demands of the duplication and replication sectors.

Omni's features allows you to identify media quality issues and highlight drive performance and recording problems.

The system is based on a Philips CD/DVD drive. It supports the majority of the optical disc formats, including CD-ROM, CD-R/RW, CD-A DVD-R/-RW, DVD-R DL, DVD+R/+RW, DVD+R DL, DVD-ROM 5 and DVD-ROM.

The platform can test the media for the following signals:

CD-R/CD-ROM/CD-A DVD+R/+RW DVD-R/-RW DVD-ROM
Reflectivity R-I14H R-I14H R-I14H
Jitter Modulation Modulation Modulation
I11/ITop Jitter Jitter Jitter
Asymmetry/Beta PI Sum 8 PI Sum 8 PI SUm 8
BLER PI Unc PI Unc PI Unc
E11 to E32 Error Statistics POF POF POF
Burst Errors Beta Beta Asymmetry
  ADER   EDC
  ADER Unc

Test speeds for CD media are set at 16X and for DVD media at 4X.

The equipment is capable of providing measurements on the complete data area or at specific positions defined by the user (Quick Test mode). This zone testing procedure allows multiple areas of the disc to be tested in a single operation.

All numerical and graphical data are stored in a database. Data can be recalled with user defined criteria to create sets of related key results. Data can also be imported into most common software packages - MS Excel etc.

For more information on the Quantized IQB Omni Analyzer, visit http://www.quantized.com.

In the following pages, we present the writing quality measurements of various CD and DVD recordable and rewritable media, burned with the Optiarc AD-7260S DVD burner.
