Thursday, August 17, 2006
ASUS EN7800GT TOP SILENT

1. Introduction

Today we will be reviewing a graphics card from ASUS, the EN7800 GT TOP SILENT. This card uses the 7800 GT graphics engine, which has slightly lower performance and price than the GTX series. The EN7800 GT TOP SILENT is suited to gamers that demand top performance but also want a zero noise PC, since most of the high-end or mid-level cards tend to be noisy, due to the high speed fan cooling system they are equipped with.

-Features and specs according to ASUS

Graphics Engine GeForce 7800GT

Video Memory

256 M DDR3, -1.6ns

Engine Clock 420MHz

RAMDAC

400MHz

Bus Standard

PCI-Express

Memory Interface

256-bit

Max Resolution

2048x1536

VGA Output

Standard 15-pin D-sub

TV Output

HDTV-out

DVI Output

DVI-I

Video Input

Yes

2nd VGA Output Yes
Adaptor/Cable bundled HDTV out adaptor
DVI-to-2nd VGA adaptor
Software Bundled King Kong
Asus GamePack1
Asus Game Pack 2
ASUS DVD XP
Media Show
ASUS Utilities & Driver
Memory Clock 1.24GHz(620MHz DDR3)

The ASUS EN7800 GT TOP SILENT is one of the highest stock overclocked 7800 GT cards on the market. The default core speed for the 7800 GT is 400MHz for core and 1.0GHz for the memory, but ASUS has successfully overclocked the EN7800 GT despite using a passive cooling system.

- Chipset Features

NVIDIA offers a complete top-to-bottom line up of NVIDIA® GeForce® graphics processing units (GPUs) that will take full advantage of the new Windows Vista™ features and functionality when the final OS is released.

NVIDIA® SLI™ Technology
Delivers up to 2x the performance of a single GPU configuration for unparalleled gaming experiences by allowing two graphics cards to run in parallel. The must-have feature for performance PCI Express graphics, SLI dramatically scales performance on over 60 top PC games.

NVIDIA® PureVideo™ Technology
The combination of high-definition video processors and NVIDIA DVD decoder software delivers unprecedented picture clarity, smooth video, accurate color, and precise image scaling for all video content to turn your PC into a high-end home theater. (Feature requires supported video software.)

NVIDIA® UltraShadow™ II Technology
The GeForce 6 and GeForce 7 Series GPUs feature the advanced UltraShadow technology, for the acceleration of complex shadows in immersive 3D games and applications.


NVIDIA® CineFX™ 4.0 Engine
Delivers advanced visual effects at unimaginable speeds. Full support for Microsoft® DirectX® 9.0 Shader Model 3.0 enables stunning and complex special effects. Next-generation shader architecture with new texture unit design streamlines texture processing for faster and smoother gameplay.


NVIDIA® Intellisample™ 4.0 Technology
The industry's fastest antialiasing delivers ultra-realistic visuals, with no jagged edges, at lightning-fast speeds. Visual quality is taken to new heights through a new rotated grid sampling pattern, advanced 128 Tap sample coverage, 16x anisotropic filtering, and support for transparent supersampling and multisampling.


PCI Express™ Support

Designed to run perfectly with the next-generation PCI Express bus architecture. This new bus doubles the bandwidth of AGP 8X delivering over 4 GB/sec. in both upstream and downstream data transfers.



NVIDIA® nView™ multi-display technology

Provides the ultimate in viewing flexibility and control for multiple monitors.

Microsoft® DirectX® 9.0 Shader Model 3.0 Support
Ensures top-notch compatibility and performance for all DirectX® 9 applications, including Shader Model 3.0 titles.

OpenGL™ 2.0 Optimizations and Support
Ensures top-notch compatibility and performance for all OpenGL applications. NVIDIA® nView® Multi-display Advanced technology provides the ultimate in viewing flexibility and control for multiple monitors.

High-Speed GDDR3 memory interface
Support for the world's fastest GDDR3 memory delivers fluid frame rates for even the most advanced games and applications.

- Packaging/Bundle

The retail box contains a VIVO cable, DVI to VGA adaptor, user manual, quick install guide, CD Wallet, PCI-E power cable, drivers and utilities. Unfortunately, it does not include a second DVI2VGA adaptor or any S-Video or Composite cables...

Bundled games:
  • ASUS Bonus GAMEPACK
    • Second Sight
    • Chaos League
    • PowerDrome
    • Savage
    • BillyBlade
    • Mashed
  • Peter Jackson's King Kong: The Official Game of the Movie

Bundled Software:

  • ASUS DVD XP
  • Media Show
  • Power Director
  • Graphic Card Mutli-language manual CD
  • ASUS Utilities & Driver
    • MS DirectX 9.0c
    • WDM Capture Driver
    • ASUS SmartDoctor
    • ASUS Video Security Online
    • GameLiveShow
    • GameFace Live
    • ASUS Enhance Driver

ASUS CD Wallet...

Quick Installation Guide...

Drivers and utilities installation guide...

VIVO cable...

DVI to VGA adaptor ...

PCI Express power cable...

Now that we have covered the card's features, let's move on and have a closer look at the card itself.
